Hi, I'd like to thanks your wonderful tool, AI Flight Planner. I'm new to AI. I'd like to convert FS9 traffic to FSX. I started with a very simple FS9 traffic. Only one A380 and one flight plan for VTBS. I have only one traffic file in Scenery/World/Scenery folder. I use your tool to check that already.

This picture is before I convert. I can see A380 in the parking bay. I use FS9 AI model and FS9 AI flight plan.

Now, I use AIFP to convert FS9 flight plan to FSX one. Let the program delete the old one out. There is only one flight plane in that folder as you can see in this picture. The result, my A380 vanish from the sight. The same time as the first picture. There must be something wrong with my process or the AIFP. I use your latest version.

Please advice me what's wrong with this. Best Regards. How To Replace Struts On 2002 Ford Escape on this page. I also let AIFP to generate text file and compiled with TTool manually. That gave me the bgl file and I tested that in FSX. The A380 disappeared too.

There must be something wrong inside the program while it is generating the flight plan text file, I guess. I used TTool again and generate text file from my original traffic file in FS9.

Sounds Reworked - Flight Sim Set Volume (FSSV) - Review; OEM B737 CDU Conversion - Using SimStacks To Convert The CDU; MCP and EFIS By SimWorld - Review. Convert Fs9 Traffic Files To Fsx Free. I usually program in Java. Now, simply place one of the ProxyUser.ini files (for the FS version you want to fly, i.e. FS9 or FSX) in the main TileProxy root. Flysimware - 1966 Old School Skylane. FSX SP2 and FSX Acceleration Pack. Addon Converter X resolves many of.

Then I changed the airplane to Thai livery by editing the text file. Old method and almost impossible if I have hundred of flight plans. Now I have A380 back. Conclusion, I use AIFP and compile the flight plan that I changed. There might be something wrong during the compile or generate text file. Even I use TTool manually from the text file that I got from AIFP, I cannot have my AI in the airport.

It is very unlikely the problem is in the AIFP compiler. It is far more likely that you have another FS9 traffic file lurking in FSX Scenery world scenery or one of your active Addon scenery folders.

Try using AIFP's FS9 traffic file search capability to locate it/them. Also, I note in your second post you had to edit the aircraft to get it to display using TTools and FS9. Are you sure, the aircraft.cfg file entry for whatever variant you were trying to display in FSX is correct and that the aircraft folder in which it resides is in a SimObjects subfolder declared in FSX. Charlie And Lola Episodes Free Download more. cfg? If you are programming for FSX, why are you creating the flight plan for FS9 and converting for FSX?

Why are you not simply compiuling the origuinal flight plan for FSX? Click to expand.Thanks for your reply, Don. Yes, I did try that and I found nothing inside. Please take a look at the third picture. I list all the file inside by date and all the default bgl will be on the upper list.

The traffic file that is fs9, I changed that file from TrafficInterVTBS.bgl to BAK. TrafficBoats.bgl and TrafficAircraft.bgl are default. TrafficCarriers.bgl is from Acceleration. Other than that are altitude change bgl from ADE. All other traffic files from FS9, I zipped them to traffic.rar file. Nevertheless, I will try to move all the files to somewhere else and see how it is.

Click to expand.Yes, I did that. As I explained to you that I simple compiled the traffic file that contain only one aircraft and one flight plan. You can see at the. I select the Traffic A380 VTBS.bgl file. That is the only one file in the Scenery/World/Scenery folder.

Then I let the program delete that file and rename as _FSX. You can see the file in the, it became Traffic A380 VTBS_FSX.bgl. I only selected that file and converted into FSX, that's it.

I swear to you, it just the only thing that I did. I didn't change anything at this point. After I cannot see the AI, I let the program generate text file and I compiled with ttool and AI still disappear. So I went back to ttool and generate text file from original FS9bgl and compile to change the livery of the airplane. Then it came to.

Dear Don, I really appreciate your effort of making this program for us, developers. But I would like to use it and it gave me a headache. I have pictures to prove. I use only one traffic file in Scenery/World/Scenery. I remove every files that control traffic even the default ones. I have only Traffic A380 VTBS.bgl in the folder. You can see this picture and it gave me A380 in the parking.

I selected that file to convert to FSX one. Let the program delete the old file and add _FSX to the file name. Then the only file that I have in this folder is Traffic A380 VTBS_FSX.bgl and you can see in the picture, my A380 is gone. I did search for this plane all over the airport and none was found. I'm not bugging you, Don. I'd like to work with your program, as much as you do. But it is not working as it should.

Would you mind checking, please? Best Regards. Click to expand.Yes, I have searched all over with your tool and the only flight plan I have is Traffic A380 VTBS.bgl. No other flight plans were found.

I'm developer so I don't have other people's AI to play around. So I gave up with FSX flight plan. No need to see FSX default flight plan. Only one flight plan compile for FS9. If you say it works on your side. So what might be the problem?

May be my system.net or other things. I think I'll change the computer to do on the other one.

May be something in the WindowsXP or.Net programs. Best Regards. I think you would want to read through the manual again because that is not the 33 minute problem (or is it 37 minutes, I do not recall?). I do not have the manual here so i cannot quote from it and it takes a lot of words to explain. It boils down to the fact that on a long distance flight the plane arrives and does not spawn (I think) within 33 minutes from its scheduled arrival time in the area. D'you see that I am bad at explaining?

How about attaching your flightplan? And what is the cruise speed of your aircraft in the aircraft.cfg?

Mission Statement The purpose of FLAPS-2-APPROACH is two-fold: To document the construction of a Boeing 737 flight simulator, and to act as a platform to share aviation-related articles pertaining to the Boeing 737; thereby, providing a source of inspiration and reference to like-minded individuals. I am not a professional journalist. Writing for a cross section of readers from differing cultures and languages with varying degrees of technical ability, can at times be challenging. I hope there are not too many spelling and grammatical mistakes. Note: I have NO affiliation with ANY manufacturer or reseller.

All reviews and content are 'frank and fearless' - I tell it as I see it. Do not complain if you do not like what you read. I use the words 'modules & panels' and 'CDU & FMC' interchangeably. The definition of the acronym 'OEM' is Original Equipment Manufacturer ( aka real aicraft part). All funds are used to offset the cost of server and website hosting ( Thank You.) No advertising on this website - EVER!

FEEDBACK: If you see any errors or omissions, please contact me to correct the information. Increased navigational accuracy obtained from software and hardware improvements have led to several enhanced approach types being developed for the Boeing 737. These augmented approach types provide a constant rate of descent, following an approximate 3 degree glide path, and eliminate the traditional step-down style of approach.

The benefits being a stabilized and safer approach, greater passenger comfort, less engine wear, tear and fuel usage, and a lower workload for the flight crew. LEFT: Nippon Airways (ANA), one of Japan’s premier airlines uses Integrated Approach Navigation (IAN) on many of its routes. Utilizing IAN can produce considerable savings to an airline by minimizing engine wear, fuel costs, and standardizing flight training. Click image to enlarge. In this post, I will discuss the concept of Integrated Approach Navigation (IAN) and explain the procedures recommended by Boeing to successfully implement IAN.

I have attempted to cover all the detail concerning IAN in one article, however, when a lot of detail is discussed it can, on occasion, lead to confusion. Therefore, I recommend you read the Boeing Flight Crew Training Manual for more in-depth information. The Navigation Performance Scales ( NPS) which augment IAN will not be discussed. NPS will form part of a future topic. Overview Integrated Approach Navigation (IAN) provides a display similar to the Instrument Landing System ( ILS) and allows the flight crew to fly any published approach that exhibits a glide path within the navigational database of the Flight Management System ( FMS).

Flight path guidance is derived from the Central Control Unit ( CDU), navigational radios (NAV1/2 & ADF 1/2), or combination of both. For IAN to engage correctly, an appropriate approach (an approach with glide path) must be selected from the CDU database. IAN is an airline option, and not every airline carrier will have IAN as part of their avionics suite.

However, the technology is becoming more popular as the safety and economic benefits of IAN are understood by airline carriers. Geometric Path The geometric path used by IAN approximates a 3 degree glide path; nevertheless, this glide path may not comply with the CDU designated altitude constraints prior to the Final Approach Fix ( FAF). This said, the generated glide path will always be at or above the altitude constraints between the FAF and the Missed Approach Point (MAP) published in the CDU approach procedure. Critically, IAN is a Category I Non Precision Approach ( NPA) and is not to be confused with an ILS precision approach. Therefore, NPA procedures must be adhered to when initiating an approach using IAN.

Although the automation provided by IAN will guide an aircraft (in most cases) to the threshold of the runway, IAN has not been designed to do this. Rather, IAN has been designed to guide the aircraft to the Missed Approach Point (MAP) published on the approach chart. The flight crew will then disengage IAN by disengaging the autopilot and autothrottle and fly the remainder of the approach manually as per NPA protocols. In some instances, the final approach course ( FAC) is offset from the runway centreline and manoeuvring the aircraft for direct alignment will be necessary, whilst following the glide path (G/P) angle.

Although the final approach is very similar to an ILS approach, IAN does not support autoland; therefore, if the aircraft is not in a stable configuration and the crew not visual with the runway at or beyond the MDA, a missed approach procedure will need to be executed Ground Proximity Warning System ( GWPS) Aural Warnings and Displays GWPS warnings will annunciate if at any time the aircraft deviates below the glide path, and failure of a crew to disengage IAN at the appropriate altitude will trigger an GPWS aural warning alert ‘ autopilot autopilot ’ at 100 feet radio altitude. This is in addition to the words ‘autopilot’ being flashed on the Primary Flight Display ( PFD). Benefits of Using IAN There are multiple benefits to an airline using IAN, the foremost being flight safety. Unstable approaches contribute to many aircraft accidents, and flight crews strive to always establish a stabilised approach profile for all instrument and visual approaches.

The Global Position System has enabled stabilized approaches at many airports and advanced features such as IAN take advantage of this technology to provide consistent, intuitive displays that support stabilized approaches. 18 Approaches Types to 1 Through the use of IAN, the number of approach types has been reduced from 18 to 1, greatly simplifying the approach procedure and minimizing the amount of time an airline needs to train pilots in numerous approach types. Time is money and utilizing advanced technology such as IAN can increase airline productivity. Additional Data - Increased Awareness The distance to runway threshold, approach guidance information, and vertical and lateral deviation markers are displayed when IAN is in range of a designated runway. W hether IAN is used or not, this information provides additional guidance when executing an approach.

For example, when executing a VOR approach, this information has been displayed on the Navigation Display ( ND) as the distance to the actual NAVAID ( VOR) - which may or may not be aligned with the threshold of the runway. IAN will by default, display the lateral and vertical deviation, and distance to the runway threshold, allowing for greater precision during a non-automated approach. These are but a few of the advantages to using the Integrated Approach Navigation system. Using IAN - General The following information provides guidance in the general use of IAN. IAN can be used for the following approach types: RNAV, VOR approach, GPS, NDB approach, LOC, LOC- BC or similar style approaches.

If using IAN to execute a Back Course Localizer approach (B/C LOC), the inbound front course must be set in the MCP course window (either Captain/First Officer side, or both depending on CDU set-up). LEFT: IAN approach to VOR/ DME RWY 24.

FAC is engaged while G/P is armed. The lateral and vertical deviation pointers are displayed and will, change colour to solid magenta when the G/P engages. A benefit if using IAN is that it provides an accurate distance from the threshold to the aircraft - in this case 9.7 miles. (ProSim737 avionics suite).

Although the use of IAN is recommended only for straight-in approaches, field use suggests that flight crews routinely engage IAN when no more than 45 degrees from the runway approach course. During the approach the crew must monitor raw data and cross check against other navigational cues. IAN does not need to be specifically ‘turned on’ for it to function; the functionality, if installed in the aircraft is always functional. When the aircraft is within range of the designated approach, the runway data will annunciate on the PFD. At any time after this point has been reached, IAN can be armed/engaged by pressing the APP button on the MCP. LEFT: An example (not related to PFD image) showing a typical CDU generated approach which is IAN compliant.

The altitude (3000 feet) positioned above the entry GP3.00 is the altitude set to the MCP altitude window. An approach may have several glide path entries; always select the first entry. CDU is manufactured by Flight Deck Solutions ( FDS). Click image to enlarge.

Navigation Radios An IAN approach can be executed without the guidance from navigation radios; however, this is not recommended as correct tuning of the radios can provide increased visual awareness and redundancy should a failure occur with the CDU, or the dataset becomes corrupted. LEFT: Montage of four PFDs showing various annunciations and displays for the IAN system. Sequence is top left to right and bottom left to right. Click image to enlarge (ProSim737 avionics suite). Boeing strongly advise to tune the radios to the correct frequency for the approach, to eliminate the possibility of the radio picking another approach from a nearby airport and providing erroneous data to the crew.

If using IAN for an ILS approach (glide slope inoperative) the radio must not be tuned to the ILS frequency. Minimum Descent Altitude ( MDA) As discussed earlier, an IAN approach is a NPA and when authorized by the Regulatory Authority, non- ILS approaches can be flown to a published VNAV Decision Altitude/Height ( DA/H) or to a published MDA (the MDA is used as a decision altitude). If not authorized to use the MDA as a decision altitude, crews must use the MDA specified for the approach flown. To comply with the MDA protocols during a constant angle approach where a level off is not planned at the MDA, it is necessary to add +50 feet to the published MDA. If a go-around is required, this allows an adequate buffer to prevent incursion below the MDA.

Using IAN - Understanding IAN Displays IAN generates several visual displays which inform the flight crew of the status of the system. These displays, which are triggered at various operational phases, are visible on the attitude display of the PFD and on the Flight Mode Annunciator ( FMA). Approach Guidance: The PFD will display the method of initial approach guidance in white whenever IAN is active. The display will differ and is dependent on the approach type selected. For example, LNAV/ VNAV, FMC, LOC or ILS, depending on the source of the navigation guidance used for the approach (navigation, radio or CDU approach data). An IAN approach will display FMC. Approach guidance is activated when a crew selects TO/GA during the take-off roll, or when the aircraft is within range for the system to be armed/engaged.

Runway Data: Whenever IAN is within range of a selected approach, the PFD will display the runway data (type and name of approach, runway designator and distance to threshold). The display of the runway data is the crew’s first ‘ notification’ that the IAN functionality is able to be used. Final Approach Course ( FAC): FAC is displayed on the center FMA when the APP button on the MCP is pressed, and IAN is in range of the approach selected. Glide Path (G/P): G/P is displayed in the right FMA to indicate that the aircraft has a associated glide path to follow. Two FMA colours are used.

White indicates that FAC or G/P is armed. Once the aircraft is closer to the Final Approach Point, the FAC annunciation will change colour from white to green. Green indicates that the final approach course is active. Likewise, when G/P changes colour to green, it indicates that the aircraft has a dedicated glide path to follow. It stands to reason, that FAC is usually annunciated prior to G/P, but depending upon the position of the aircraft when APP in pressed on the MCP, both annunciations may annunciate singly or together, in white or in green.

Lateral and Vertical Guidance Deviation Markers: These are the magenta coloured diamonds, familiar to ILS approaches. The diamonds provide the lateral position of the aircraft relative to the designated runway course and the vertical position relative to the glide path. The diamonds are initially displayed in outlined magenta followed by solid magenta when the aircraft captures the glide path.

SINGLE CH: SINGLE CH will be displayed in green, when the aircraft captures the glide path. At this time, the deviation markers will change from outline to solid magenta.

FAC and G/P on the FMA will also change from white to green. At this point the aircraft will be guided automatically along the glide path. Using IAN - Proceedure • IAN is engaged only after clearance for final approach has been received from Air Traffic Control ( ATC). By this time, the aircraft is probably on a straight in approach. IAN is not designed to navigate to the airport.

• IAN cannot be used for STARS and is not designed to be engaged when the aircraft is miles from the designated runway. Flight crews transition to an IAN approach from any of several roll modes ( VNAV/ LNAV, Level Change, V/S or manual-controlled flight). • To arm/engage IAN, the flight crew press the APP button on the Mode Control Panel ( MCP) similar to performing an ILS approach.

The APP mode is only to be selected when: • The guidance to be used for the final approach is tuned and identified on the navigation radio; • An appropriate approach has been selected from the CDU database which has a glide path attached to it; • The appropriate runway heading is set on the MCP course window; • The aircraft is on an inbound intercept heading; • ATC clearance for the approach has been received; and, • Both lateral and vertical deviation pointers are visible on the attitude display in the PFD. IMPORTANT NOTE: It is possible to select APP prior to the display of the deviation pointers, however IAN will be in armed mode. IAN will only engage following aircraft capture of either the lateral or vertical flight path (FAC & G/P). IAN can be armed whenever the aircraft is in range of the airport - in other words whenever the runway data is displayed on the PFD.

Many flight crews engage IAN only after the deviation pointers are visible (this follows the similar ILS approach method). Using IAN - Set-Up • Select the appropriate approach to use from the CDU database. Ensure that the selected approach has a glide path. Do not alter any of the approach constraints. Set the glide path altitude to the MCP altitude window.

• Fly the aircraft in whatever roll mode to the Initial Approach Fix ( IAF). Remember straight-in approaches are recommended – a 45 degree offset to the approach course is also suitable (varies). Do not engage IAN until the aircraft is in the correct position relative to the approach course.

IAN will usually become active – the approach guidance will be displayed on the PFD – at around 20 miles from the runway threshold. • Configure the navigation radios to the correct frequency for the designated approach. Do not use an ILS frequency. • Set the barometric minimums to the altitude published on the approach chart. Add 50 feet to avoid breaking NPA protocols. • Set the correct runway approach course to the MCP course window.

• When the runway data is displayed on the PFD, IAN is in range. At this point, the APP button on the MCP is pressed to arm IAN (this action can be delayed if not on straight-in approach heading). The FMA will annunciate FAC and G/P in white to indicate the IAN system is armed. • When the aircraft is alligned with the lateral and vertical profile, the colour of the FAC and G/P annunciations will change from white (armed) to green (engaged). The lateral and vertical deviation markers will also annunciate with a magenta outline. • As the aircraft closes on the runway threshold, and when the glide path has been reached, the deviation markers will become solid magenta and SINGLE CH will annunciate on the PFD. The FAC and G/P annuniations on the FMA display will now be green.

The aircraft will begin to descend along the glide path. • Once the aircraft has descended, at least 300 feet below the altitude previously set in the MCP altitude window; the missed approach altitude (MAA) can be set on the MCP. This figure is published on the approach chart.

Failure to wait until the aircraft descends 300 feet will cause the ALT HOLD annunciation to display and the aircraft levelling off. Using IAN - Pilot Procedures The procedures used for an IAN approach are derived from current ILS procedures and are consistent for all approach types.

This is the procedure after IAN has engaged. • When 2 miles from the Final Approach Fix ( FAF) - GEAR DOWN, FLAPS 15, SPEED CHECK. • At glide path capture – FLAPS 25/30 (landing flaps), SPEED CHECK.

• At 300 Feet below glide path capture, reset the MCP altitude window to the missed approach altitude. • At minima – Disengage autopilot and autothrottle, manually align aircraft and follow vertical deviation markers and Flight Director ( FD) cues to runway threshold.

Maintain the glide path to the flare and do not descend below the visual glide path. Although glide path guidance can be used as a reference once the aircraft descends below the MDA, the primary means of approach guidance is visual.

If not visual at MDA, execute a go-around. Remember using IAN is a Non Precision Approach (NPA). IMPORTANT NOTE: The transition from roll mode to IAN approach can be quite sudden and a flight crew must be vigilant and anticipate actions and events before they occur. If the aircraft is travelling too fast, slowing down after IAN has engaged can be difficult.

Likewise, if the aircraft is too high and IAN engages, the vertical descent can be steep as the aircraft attemptes to follow the IAN generated glide path. Therefore, maintaining the correct approach speed and altitude is paramount to a successful IAN approach.

If using VNAV, it often is good idea to engage to manually control MCP speed. Flight crews often transition to IAN from whatever automation mode they are using at the Initial Approach Fix (IAF), or they manually follow the deviation pointers generated by IAN until confident that the aircraft will not behave erratically when IAN is engaged by pressing the APP button on the MCP. FIGURE 1: Visual representation of an IAN approach and transition from roll mode.

Copyright Boeing FCTM, 2014. On another note, when an IAN approach mode is selected, the APP mode in the EFIS can be selected to display the approach (as in an ILS approach in the Navigation Display). Using IAN - Situations To Be Mindful Of Automation can have its pitfalls, and IAN is no different. However, once potential shortcomings are known, it is straightforward to bypass them. The most common mistake, especially with virtual pilots, is not following the correct procedure. Possible ' surprises ' associated with IAN are: 1: Failing to configure the aircraft prior to IAN engaging in FAC and G/P mode. Unlike an ILS approach, where configuration for landing is initiated when the glide slope comes alive (solid magenta deviation markers), during an IAN approach, configuration for landing is initiated approximately 2 miles from the Final Approach Fix ( FAF).

The reason for this, as discussed in the overview section, is that IAN creates a glide path from the designated runway threshold to the position of the aircraft. If the crew wait until the IAN glide path becomes alive (solid magenta deviation pointers), there may be insufficient time for the crew to complete recommended actions and checklists before intercepting the glide path. 2: Forgetting to set the Missed Approach Altitude (MAA) in the MCP. Failing to wait until the aircraft has descended 300 feet below the glide path capture altitude to reset the MCP altitude to the MAA. Failure will cause the aircraft to revert to ALT HOLD. 3: Approaching the runway not on the correct intercept course IAN operates flawlessly with straight-in approaches and to a certain extent with approaches roughly 45 degrees from the main approach course.

IAN will not engage if you approach the assigned runway at 90 degrees. Nor will IAN engage if you are attempting to fly a STAR.

4: Transition from roll mode to the IAN approach can be abrupt with loss of some visual data The PFD will display differing annunciations depending on the type of approach configured from the CDU database, and the roll mode being flown prior to IAN engaging. When IAN is in range, some of this displayed data will be replaced with data from the IAN system. For example, if the primary navigation is using VOR/LOC, and when IAN comes into range, the approach guidance, runway data and deviation markers will be displayed in the PFD. However, simultaneously, the Navigation Display ( ND) will display EFIS MODE/ NAV FREQ DISAGREE. If executing a VOR approach, and not wanting to use IAN, loosing the VOR directional marker in the ND, if unexpected, can be disconcerting. Note that this will occur whenever IAN is in range of the designated runway (IAN does not necessarily have to be armed or engaged) But, be assured that the VOR/LOC is still being followed, despite the VOR directional marker not being able to be viewed in the ND.

The FMA will indicate what the aircraft is doing - in this case the FMA will display VOR/LOC (always y look at the FMA to determine what level of automation the aircraft is using). 5: Forgetting to set the altitude in the MCP (from the CDU glide path) A common mistake is to not set the altitude in the MCP altitude window to the altitude that is associated with the glide path for the desired approach.

ProSim737 and IAN Integrated Approach Navigation has only recently been introduced to the ProSim 737 avionics suite (late December 2014). As such, there are ‘ teething issues’ associated with its use. With time, it is envisaged that the developers of ProSim737 will rectify shortfalls to ensure accurate and trouble free operation. Five known shortfalls at the time of writing are: (i) ProSim737 does not display the IAN runway data immediately following the engagement of TO/GA during the take-off roll. This is incorrect. In the real aircraft, this information is displayed immediately following the engagement of TO/GA during the take-off roll while the aircraft is on the ground. (ii) The colour of the approach guidance display (LNAV/VNAV) after TO/GA is engaged is currently white.

This is incorrect. The colour should be green ( further research required, F2A). (iii) The runway data and approach guidance displays are not identical to the real aircraft – they are the incorrect font size.

This is a minor issue. (iv) Interestingly, ProSim737 allows an IAN approach to dunction with any CDU generated approach procedure (with or without glide path). This is incorrect. An IAN approach can only be generated with an approach that displays a glide path. Although the reason for this is uncertain, I am lead to understand that it is associated with the navigational database, which is beyond the scope of ProSim737 (course is an outside source).

(v) Once IAN is armed/engaged and an approach selected from the FMC database via the CDU, the ability to fly a standard VOR approach ceases. The message EFIS MODE NAV FREQ DISAGREE will be displayed on the Navigation Display when VOR is selected on the EFIS. The only way to fly a VOR approach is to not select a VOR approach from the FMC database. This is not correct. IAN should not take control of a VOR approach. ProSim737 users should also note, that for IAN to function within the avionics suite, it must be activated in the cockpit set-up page of the instructor station (IOS). Final Call Aircraft fitted with IAN, are capable of using the APP button located on the MCP, to execute an instrument ILS-style approach based on flight path guidance from the CDU.

This makes Non Precision Approaches easier to execute with increased safety. It also enables a constant descent angle, less engine spooling, wear and tear, and improved passenger comfort. Furthermore, IAN utilises a standardised procedure and as such, when installed, is usually used in place of LNAV and VNAV due to its straightforward method of use. Nevertheless, a flight crew must be vigilant when using any automation, especially during the critical approach phase where there is little margin for error. First and foremost is the innate ability to fly the airliner manually, and although automation such as IAN can enhance safety, it does so at the detriment of manual flying skills. References Several sources were used to obtain the information documented in this post, including: personal communication with a B737-800 pilot, the Boeing Flight Crew Training Manual, 2014 and the Boeing 737 Technical Guide by Chris Brady.

If any discrepancies are noted in this article, please contact me so they can be rectified.
